Product Overview
This product is a 6-meter two-section fire ladder, model TEL6. The main body is made of aluminum alloy and complies with the XF137-2007 Fire Ladder standard.
The 6m Double Extension Ladder has passed type testing conducted by the National Fire Equipment Quality Supervision and Inspection Center and has obtained CCC certification from the Fire Product Conformity Assessment Center of the Ministry of Emergency Management. All test results meet the required standards.
Basic Parameters
The working length is 6 meters, with a tolerance of ±0.2 meters.
The minimum ladder width is 300 mm, with a tolerance of ±3 mm.
The rung spacing is 340 mm, with a tolerance of ±2 mm.
The total ladder weight is 29 kg, with a tolerance of ±2 kg.
Materials and Components
The side rails, rungs, and support legs are all made of aluminum alloy.
All core components are constructed from aluminum alloy, ensuring both strength and practical usability.
Performance Characteristics
The horizontal bending residual deformation ratio is 0.038%, which is far below the standard requirement of 0.30%.
After completion of the single-leg load test, the support legs and their connecting fittings showed no loosening, damage, or deformation.
During the impact resistance test, the support legs maintained normal support function. After testing, neither the support legs nor the rungs showed any significant deformation or damage.
Accessories and Workmanship
A dedicated nameplate is affixed to the right side rail, displaying the 6m Double Extension Ladder name, model, specifications, and other required information. An instruction manual is included.
All components are precisely manufactured, connections are secure, and the overall workmanship is solid, meeting the requirements for fire protection products.
